Dockerize My Network

Posted Mar 29, 2021 Updated Jan 11 4 min read

Current network architecture

Visual diagram

Just a sketch.

Network arch

So-called safe LAN, in which there will be no unexpected public traffic inbound under normal circumstances.

  • In local LAN, use socks5 and http for next_hop in v2ray. (2 ports needed)
  • In openvpn nat LAN, use http with proxy automation script(pac) to proxy gfw network flow to v2ray .(1 port needed)
  • Manual Proxy certain traffic to docker container unblocknetease.(1 port needed)

Public network(In my case, i have a public ip addr and pre-configured ddns)

  • Use vmess inbound with tls. (1 port needed)
  • Inside v2ray, use routing to pass traffic to unblocknetease.(docker network port binding needed)

In this situation, I have to utilize/listen/bind at lease 4 to 5 ports to get a fully functional “gateway”.

Modifications

Combine native-runtime v2ray and docker container unblocknetease into one single docker container. Server as a “gateway” and Bind only 2 ports.

  • Inbound 1: http
  • Inbound 2: vmess

All traffic redirected to unblocknetease will be handled by v2ray’ s routing feature.

Dockerfile

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48

ARG APLINE_VERSION=3
FROM alpine:${APLINE_VERSION}

LABEL maintainer="Mijazz_Chan"
LABEL version="1.0"

ARG V2RAY_VER="4.34.0"
ARG UNBLOCK_NETEASE_VER="0.25.3"

ARG SYSTEM_ARCH="linux-64"

# PRODUCTION ENV
ENV V2RAY_BINARY="https://github.com/v2fly/v2ray-core/releases/download/v"${V2RAY_VER}"/v2ray-"${SYSTEM_ARCH}".zip"
ENV UNBLOCK_NETEASE_SRC="https://github.com/nondanee/UnblockNeteaseMusic/archive/refs/tags/v"${UNBLOCK_NETEASE_VER}".zip"
ENV NODE_ENV=production
ENV NPM_REG="https://registry.npmjs.org"


# DEVELOPMENT ENV
#ENV V2RAY_BINARY="http://download.mijazz.xyz/v2ray-linux-64.zip"
#ENV UNBLOCK_NETEASE_SRC="http://download.mijazz.xyz/v0.25.3.zip"
#ENV NPM_REG="https://registry.npm.taobao.org"


# Due to known network issue, you may need to uncomment this line or change mirrors
#RUN sed -i 's/dl-cdn.alpinelinux.org/opentuna.cn/g' /etc/apk/repositories

RUN apk add --update nodejs npm supervisor && \
    wget -O /tmp/v2ray.zip $V2RAY_BINARY && \
    wget -O /tmp/v2ray.zip.dgst $V2RAY_BINARY.dgst && \
    expect_md5=`awk '/MD5/{print $2}' /tmp/v2ray.zip.dgst` && \
    current_md5=`md5sum /tmp/v2ray.zip | cut -d' ' -f1` && \
    if test "$expect_md5" != "$current_md5"; then echo "Corrupt File"; exit -2; fi && \
    echo -e "\n=====V2ray Fetched=====\n=====MD5 CHECKSUM MATCH=====\nExpecting: $expect_md5\nCurrent:   $current_md5\n" && \
    unzip -q -d /opt/v2ray /tmp/v2ray.zip && \
    wget -O /tmp/unblock_netease.zip $UNBLOCK_NETEASE_SRC && \
    unzip -q -d /opt/unblocknetease /tmp/unblock_netease.zip && \
    mv $(find /opt/unblocknetease -mindepth 1 -maxdepth 2) /opt/unblocknetease/ && \
    npm --registry $NPM_REG install --production /opt/unblocknetease && \
    rm -rf /tmp/* /var/cache/apk/*

COPY ./server.crt /opt/unblocknetease/server.crt
COPY ./server.key /opt/unblocknetease/server.key

VOLUME /conf

ENTRYPOINT ["supervisord","--nodaemon", "--configuration", "/conf/supervisord.conf"]
  • volume for /conf should contain a valid v2ray json config, supervisord config.
  • Upstream project unblocknetease does not provide a configurable certificate path, you must have to follow this github issue to sign/generate your own certificates.
  • Certificates are being COPY into docker image during docker build procedure.

Files

1
2
3
4
5
6
7
8
9
10
11
12
13
14

 ~/Dev/otherproject/net-breach  tree .                [Mon Mar 29,06:36:40 PM]
.
├── Dockerfile
├── server.crt
└── server.key

0 directories, 3 files

 ~/Dev/otherproject/netbreach-conf  tree .            [Mon Mar 29,06:37:35 PM]
.
├── supervisord.conf
└── v2ray.conf

0 directories, 2 files

supervisord.conf

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27

[supervisord]
nodaemon=true
logfile=/dev/stdout
logfile_maxbytes=0
loglevel=info

[supervisorctl]
serverurl=unix:///tmp/supervisor.sock

[program:v2ray]
priority=2
command=/opt/v2ray/v2ray -c /conf/v2ray.conf
stdout_logfile=/dev/stdout
stdout_logfile_maxbytes=0
autorestart=unexpected
startsecs=10
exitcodes=23
startretries=3

[program:unblocknetease]
priority=1
directory=/opt/unblocknetease
command=node app.js -p 50000:50001 -o kuwo qq joox kugou -e https://music.163.com
stdout_logfile=/dev/stdout
stdout_logfile_maxbytes=0
startsecs=10
startretries=3

v2ray.conf

project related config parts

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24

#OUTBOUND
{
            "tag": "netease",
            "protocol": "http",
            "settings":{
                "servers": [
                    {
                        "address": "127.0.0.1",
                        "port": 50000
                    }
                ]
            },
            "streamSettings": null,
            "mux": null
}
# ROUTING
{
                    "type": "field",
                    "outboundTag": "netease",
                    "domain": [
                        "music.163.com",
                        "music.126.net"
                    ]
},

Cli

1
2
3

sudo docker build -t net-breach:0.1 $NET_BREACH_PATH

sudo docker run $ASSIGN_RUNTIME(rm/it/restart policy) -p $PORT_BINDING  -v /home/mijazz/Dev/otherproject/netbreach-conf:/conf net-breach:0.1
  • Port 50002 for http inbound.
  • Port 50003 for vmess inbound.

No extra port needed. Traffic routing is done by v2ray inside the container.

1
2

2021-03-29 18:55:38,043 INFO success: unblocknetease entered RUNNING state, process has stayed up for > than 10 seconds (startsecs)
2021-03-29 18:55:38,044 INFO success: v2ray entered RUNNING state, process has stayed up for > than 10 seconds (startsecs)

Few extra notes

  • Container timezone inside alpine image is not set, or not correct. Normally this will not cause any issue, but since vmess protocol is being used, it is recommended that you should bind/configure a read-only host timezone file to container.
  • Proxy next hop can be reached via inbound traffic, unblocknetease is also fully functional during test.
  • The way I handle params is not recommended with docker build procedure. (Whatever…It works…)
  • Supervisord conf probably needs a little tweaking, combination with http server and DOCKER HEALTHCHECK is more elegant. (Although this primitive way works…….In case of network issues, just restart docker container via docker restart policy)

Result

Redirect ALL traffic by vmess protocol via public network inbound.

iPhone - iOS 13, (jailbroken-not related), with certificate trust.

Network arch

Network arch

References

Disclaimer

  • This post or project does NOT endorse, claim or imply that you could use this as a tool of bypassing government network censorship or anonymizing your network activities.
  • If any unit or individual that the project may be suspected of violation of their rights, you should promptly notify and provide proof of identity and proof of ownership, I will remove the relevant content after receiving certification documents.
